Tenax Geogrids

Tenax Geogrids

Our Tenax MS 220 and MS 330 Geogrids Geogrids are affordable alternatives and a functionally equivalent equal to Tensar BX1100 & BX1200.
Tenax Corp
L and M Supply Geogrids by Tenax & SYNTEC provide the flexibility needed for easy installation and the stiffness and junction strength to stay in place. Our MS 220 and MS 330 & SYNTEC SBX11 & SBX12 Geogrids are an affordable alternative and a functionally equivalent equal to the Tensar BX1100 & BX1200.
For more information or to request pricing, please call 800-948-7870 or 912-534-6071 or use our contact form.
Tenax Geogrids Offer:
  • High Tensile Strength
  • High Junction Strength
  • High Mechanical Interlock
  • High Tensile Modulus
  • High Resistance
Soil Stabilization
Geogrids are used in soft soil stabilization applications to help facilitate the more efficient and predictable stabilization of poor soils for future construction projects.

Tenax MS220 and MS330 geogrids are composed of two and three layers of high strength, extruded biaxially oriented polypropylene grid, respectively. The layers are designed to accomodate find-grained, cohesive and non-cohesive fills as well as small sized random fill.
Base Reinforcement:
In base reinforcement applications such as paved or unpaved roads, geogrids are used to provide reinforcement and confinement to base course materials.
Stress Transfer Mechanisms
Multiple Layers - Because of the multiple layers, Tenax MS series geogrids provide a three dimensional separation effect not provided by any other geogrid. This effect keeps the fill material where it belongs. If the fill does get by the top layer, the other layers prevent any further micration.
Variable Apertures - The aperture geometry of Tenax multi-layered geogrids is purposely designed to be variable. This is done to increase the interaction and compatibility between the geogrid reinforcement and fill materials with wide ranges of particle size distribution.
Applications:
Tenax MS220 and MS330 geogrids distribute applied loads over a greater area reducing vertical pressure on the subgrade. This allows for a longer design life compared with a similar unreinforced section. If designing for a specific lifetime, this allows for significant reductions in base course thickness.
TENAX MS 220
TENAX MS 220 is composed of two layers of high strength extruded biaxial oriented polypropylene geogrids. The layers are rolled and stitched together without superimposing the grids creating a geogrid with random sized apertures designed to accommodate a variety of fill materials. The random aperture geometry, many tensile elements, and multiple layers of the geogrid enhance soil/geogrid interaction. TENAX MS 220 geogrid greatly improves the geogrid interlocking capacity, distributes applied loads, and prevents localized shear failure.
Roll Size: MS 220 Geogrid 13.1’ x 328’ - Total area per roll: 477.42 sy
Typical applications:
  • Soft soil stabilization
  • Base reinforcement
  • Embankments over soft soils
  • Working platforms
  • Haul roads etc.
TENAX MS 330
TENAX MS 330 is composed of three layers of high strength extruded biaxial oriented polypropylene geogrids. The layers are rolled and stitched together without superimposing the grids creating a geogrid with random sized apertures designed to accommodate a variety of fill materials. The random aperture geometry, many tensile elements, and multiple layers of the geogrid enhance soil/geogrid interaction. TENAX MS 330 geogrid greatly improves the geogrid interlocking capacity, distributes applied loads, and prevents localized shear failure.
Roll Size: MS 330 Geogrid 13.1’ x 164’ - Total area per roll: 238.71 sy
Typical applications:
  • Soft soil stabilization
  • Base reinforcement
  • Embankments over soft soils
  • Working platforms
  • Haul roads etc.
L & M Supply is the authority on affordable Geogrid. For more information or for a quote please call 800-948-7870 today!
